Features
- 80 PLUS Bronze certified
- 120mm Silent Hydraulic Bearing (HYB) Fan
- Reliable flat cable
- Single +12V rail
- OVP/OPP/SCP/UVP/OCP/OTP protection
- 3 years warranty (Adjusted according to different regions)
####
- Model: P550B
- Type: Intel Form Factor ATX 12V v2.31
- PFC: Active PFC(>0.9 typical)
- Input Voltage: 100-240 Vac(full range)
- Input Current: 8-4 A
- Input Frequency: 60-50 Hz
- Output Capacity: 550W
- Dimension: 150 x 140 x 86 mm
- Fan Type: 120mm Hydraulic Bearing (HYB) Fan
- 80 PLUS: Bronze
- Efficiency: 85% at typical load
- MTBF : >100,000 hours
- Protection: OVP/OPP/SCP/UVP/OCP/OTP
- Power Good Signal: 100-500ms
- Hold Up Time: >16ms
- Cable Type: Flat, All black
- ConnectorsATX/MB 20+4 Pin x 1 : 550mm*1
CPU/EPS 4+4 Pin x 1 : 600mm*1
PCI-e 6+2 Pin x 2 : 550mm+150mm*1
SATA x 6 : 500mm+120mm+120mm*2
4 Pin Peripheral x 3 + 4-Pin floppy x 1 : 500mm+120mm+120mm+120mm*1
